Friday Morning Session I (8:30 - 10:00 am)
Decoupling Capacitors
- Loop inductance, ground bounce and power rail collapse
- Decoupling capacitor impact on power integrity and emissions
- Value, placement and use of multiple capacitors
- Measurement - Decoupling capacitor impact on power distribution network (PDN)
Embedded Capacitance
- Embedded capacitance between adjacent power and ground planes
- Impact of the power-ground plane spacing on impedance
- Measurement - Power-ground plane spacing impact on impedance
Decoupling Capacitors and Embedded Capacitance
- Impact of both decoupling capacitors and embedded capacitance on PDN impedance
- Impact of capacitor spacing and power-ground planes spacing
- Measurement - Decoupling capacitors and planes impact on impedance
